Philips 75" BDL4003H H-Line High Bright Digital Signage Display

SKU: 75BDL4003H
$9,540.00
Location Availability
Sydney + 10
Brisbane Call For Availability
Melbourne Call For Availability
Perth Call For Availability

Details

Vibrant visibility in every lighting condition

High bright 24/7 display

Stay visible day and night with Philips H-Line high bright displays. Astonishing clarity and contrast make this a perfect solution for showcasing engaging content in windows and lighter locations. From airports to shopping malls, and more.


Effortless setup. Total control.

• CMND & Create. Develop and launch your own content

• Add Android processing power with an optional CRD50 module


Versatile system solution

• OPS slot allows for PC embedding without cabling

• Designed for extreme conditions

• FailOver. Ensure your display never goes blank Superb picture.


Ultra-high brightness.

• IPS panel: rich color consistency from every angle

• Ultra-HD. Rich images. Stunning contrast

• Ultra-high brightness street signage

• Built-in ambient light sensor - automated brightness control

CMND & Create

Take control of your content with CMND & Create. A drag-and-drop interface makes it simple to publish your own content-whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure your stills, text, and video will be up and running in no time.

FailOver

Critical for demanding commercial applications, FailOver is a revolutionary technology that automatically plays back-up content on screen in the unlikely event of a media player failure. Simply select a primary input connection and a FailOver connection and you are ready for instant content protection.

OPS slot

Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.

Optional CRD50 module

Embed an Android System-on-Chip (SoC) in your Philips Professional Display. The optional CRD50 module is an OPS device that enables Android processing power without the need for cables. Simply slide into the OPS slot, which contains all the connections needed to run the module (including power supply).

Extreme conditions

Enhanced thermal management, High Tni Liquid Crystals panels and built-in thermal sensors to cope with high ambient temperatures (sunlight or other) up to 3000cd/m². Display polarizer compatible with polarized sunglasses for sunlight readability.

High brightness

High-brightness street facing digital displays command attention in any lighting condition, boosting store exposure and attracting customers. Spectacular brightness of up to 3000 cd/m² ensures high visibility and pure image quality, even in extreme ambient light conditions.

Specifications

Picture/Display
Diagonal screen size74.5 inch / 189.3 cm
Panel resolution3840 x 2160
Optimum resolution3840 x 2160 @ 60Hz
Brightness3000 cd/m²
Dynamic contrast ratio500,000:1
Response time (typical)8 ms
Aspect ratio16:9
Viewing angle (H / V)178 / 178 degree
Pixel pitch0.429 x 0.429 mm
Display colors1.07 Billion
Picture enhancement3/2 - 2/2 motion pull down, Progressive scan, Dynamic contrast enhancement
Panel technologyIPS
Contrast ratio (typical)1200:1
Supported Display Resolution
Computer formats640 x 480, 60, 67, 72, 75Hz
720 x 400, 70Hz
800 x 600, 60, 72, 75Hz
1024 x 768, 60Hz
1280 x 768, 60Hz
1280 x 800, 60Hz
1280 x 1024, 60Hz
1360 x 768, 60Hz
1600 x 1200, 60Hz
1920 x 1080, 60Hz
1920 x 1200, 60Hz
3840 x 2160, 30Hz
3840 x 2160, 60Hz
Video formats480i, 30, 60Hz
480p, 60Hz
576p, 50Hz
576i, 25, 50Hz
1080i, 25, 30Hz
1080p, 50, 60Hz
3840 x 2160, 30Hz
3840 x 2160, 60Hz
Connectivity
Video inputDisplayPort (1.2), DVI-I (digital + analogue) 1x, HDMI 2.0 (x3)
Audio input3.5 mm jack
Video outputDisplayPort 1.2 (x1), HDMI 2.0 (x1)
Audio output3.5mm jack
External controlIR (in/out) 3.5 mm jack, RJ45, RS232C (in/out) 2.5 mm jack
Other connectionsOPS, USB 2.0 (x2)
Convenience
PlacementLandscape (24/7), Portrait (24/7)
Screen saving functionsPixel Shift, Low Brightness
Signal loop throughDisplayPort, RS232, HDMI, IR Loopthrough
Ease of installationCarrying Handles, Smart Insert
Energy saving functionsSmart Power
Network controllableRS232, LAN (RJ45)
Keyboard controlHidden, Lockable
Remote control signalLockable
Operating conditions
Temperature range (operation)0 ~ 40 °C
Temperature range (storage)-20 ~ 60 °C
Relative humidity20 ~ 80 %
Altitude0 ~ 3000 m
MTBF50,000 hour(s)
Power
Consumption (Typical)510 W
Consumption (Max)790
Standby power consumption<0.5W
Mains power100 ~ 240 VAC, 50 ~ 60 Hz
Sound
Built-in speakers2 x 10W RMS
Accessories
Included AccessoriesEdge Alignment Kit, Philips logo (x1), RS232 daisy-chain cable, Wire Clamper (x3), AC switch cover & Screw x1, USB cover and screws, AC Power Cord, HDMI cable, IR sensor cable (1.8 m) (x1), Open frame kit, Quick start guide (x1), Remote control & AAA batteries, RS232 cable
Miscellaneous
On-Screen Display LanguagesArabic, English, French, German, Italian, Japanese, Polish, Portuguese, Russian, Spanish, Simplified Chinese, Turkish, Traditional Chinese
Regulatory approvalsCE, CB, EAC, UL
Warranty3 year warranty
Multimedia Applications
USB Playback VideoAVI, MP4, MPEG, MPG, TTS, VOB
USB Playback PictureBMP, JPEG, PNG
Dimensions
Set dimensions (W x H x D)1688.2 x 966.6 x 111.1 mm
Set dimensions in inch (W x H x D)66.46 x 38.06 x 4.37 inch
Bezel width18.8 (even bezel)
Wall Mount600 x 400 mm, M8
Smart insert width180 mm
Smart insert height300 mm
Product weight54.1 kg
Product weight (lb)119.27 lb
